6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module

Name: 6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module
Brand: Emson Power Engineers
Price: 7000.0 INR
Availability: InStock

Price 7000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module Specification

Feature
Short-circuit and Overload Protected

Mounting Type
DIN Rail

Overheating Protection
YES

IP Rating
IP20

Shape
Rectangular

Connector Type
BaseUnit Compatible

Humidity %
5-95% (Non-Condensing)

Surface Finish
Matte

Efficiency
High Switching Efficiency

Insulation Material
Polycarbonate

Operating Temperature
-30 to +60 C

Product Type
Digital Output Module

Application
Industrial Automation, I/O Expansion for ET 200SP System

Protection Level
IP20

Frequency (MHz)
50-60 Hz

Rated Voltage
24 V DC

Energy Consumption
Approx. 0.5 W

Output Type
Digital

Color
Gray

Dimension (L*W*H)
73 x 15 x 58 mm

Weight
27 g

Size
Standard ET 200SP Module Size

Phase
Single Phase

Input Voltage
24 V DC

Connection Type
Push-in (Spring Loaded) Terminal

No Of Poles
4

Material
Plastic, Metal

Hot Swapping
Supported

Load Type
Resistive, Inductive Loads

Diagnostics
Channel Diagnostics and Wire-Break Detection

Switching Current per Channel
Up to 2 A

Isolation
500 V (Field-Backplane Bus)

Channel
4 Channels

Compatible BaseUnit
BU type A0/A1/A2

Article Number (6ES7)
6ES7132-6BF00-0CA0

Series
SIMATIC ET 200SP

Status Display
LED Per Channel

6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
4 Week

About 6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module

Output Type	Digital
Brand	Siemens
Manufacturer Series	6ES7132-6BF00-0CA0
I/O Points	8 DQ
Mounting Type	DIN Rail
Usage/Application	PLC
Availability	In Stock

SIMATIC ET 200SP, digital output module, DQ 8x 24VDC/0.5A High Feature, source output PNP, source output, Packing unit: 1 unit, suitable for BU type A0, color code CC02, Channel diagnostics for: Short-circuit and wire break; supply voltage, channel fault LED

Seamless Integration for ET 200SP Systems

Designed specifically for the SIMATIC ET 200SP automation platform, this module facilitates straightforward expansion of your digital outputs. Its standard dimensions and compatibility with BU type A0/A1/A2 BaseUnits ensure flexible and reliable installation in new or existing setups. Industrial operators benefit from easy push-in connections and efficient DIN rail mounting, enhancing system scalability.

Reliable Operation in Demanding Environments

Experience uninterrupted performance with the module's robust design features. With an operational temperature range from -30 to +60C and 500 V field-bus isolation, it delivers trustworthy output even in challenging conditions. The IP20-rated enclosure and short-circuit, overload, and overheating protections further enhance longevity and safety in industrial applications.

Advanced Diagnostics and User-Friendly Interface

Stay informed and address issues rapidly with built-in channel diagnostics and wire-break detection. Each channel provides a dedicated LED status indicator for straightforward monitoring. Maintenance teams appreciate hot swapping support, allowing for quick module replacements without system downtime.

FAQ's of 6es7132-6bf00-0ca0 Simatic Et 200sp, Digital Output Module:

Q: How can I connect the 6ES7132-6BF00-0CA0 digital output module to an ET 200SP system?

A: The module is installed by mounting it on a compatible ET 200SP BaseUnit (A0, A1, or A2) via a standard DIN rail. Its push-in (spring-loaded) terminals make wiring straightforward, ensuring rapid and reliable connection to your control panel.

Q: What types of loads and currents can this digital output module handle?

A: It supports both resistive and inductive loads, with each of its four channels capable of switching up to 2 A. This versatility allows it to control a wide range of industrial actuators and devices.

Q: When should diagnostics and wire-break detection features be utilized?

A: Channel diagnostics and wire-break detection are active during module operation, continuously monitoring output integrity. These features quickly alert users to issues such as damaged wiring or faulty connected loads, enabling timely maintenance.

Q: Where can the module be used within an industrial automation system?

A: The 6ES7132-6BF00-0CA0 is suitable for industrial environments requiring reliable digital output expansion, particularly within ET 200SP distributed I/O stations. Its IP20 rating and operational tolerances make it ideal for control cabinets and protected machine enclosures.

Q: What is the process for replacing the module during operation?

A: Thanks to its hot swapping capability, the module can be replaced without shutting down the system. Simply disconnect and remove the faulty unit, then insert the new module into the existing BaseUnit; the system will automatically recognize and configure the new hardware.

Q: How does the module's protection system benefit long-term operation?

A: Short-circuit, overload, and overheating protections safeguard the module and connected devices against damage, reducing maintenance costs and enhancing operational reliability over time.
