S200 SERVO CABLE 6FX3802-7CD01-1AF0 Dual cable, Preassembled

Send Inquiry

Request To Call Back

S200 SERVO CABLE 6FX3802-7CD01-1AF0 Dual cable, Preassembled

Price 12800.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

S200 SERVO CABLE 6FX3802-7CD01-1AF0 Dual cable, Preassembled Specification

Surface Finish
Smooth

Humidity %
Max. 90% (non-condensing)

Mounting Type
Plug-and-Play

Insulation Material
PUR (Polyurethane)

IP Rating
IP65 at Connection

Shape
Round

Connector Type
Pre-assembled with Siemens Power and Encoder Connectors

Feature
Halogen-free, Oil Resistant, Flame Retardant

Operating Temperature
-25C to +60C

Product Type
Preassembled Dual Cable

Application
For SINAMICS S120 and SIMOTICS S-1FK7/1FT7/1PH8 Motors

Protection Level
High Mechanical Protection (drag chain suitable)

Frequency (MHz)
50-60

Rated Voltage
600 V

Output Type
Power and Signal

Color
Black (Outer Sheath)

Dimension (L*W*H)
Cable Length: 10 m

Weight
Approx. 2.8 kg (depending on length)

Input Voltage
600 V AC/DC

Phase
Three Phase

Size
4x1.5 mm + 2x2.5 mm

Material
Copper Core, PUR Outer Sheath

Connection Type
Preassembled with Connectors

No Of Poles
6+2

Standards Compliance
UL, CSA, CE

Shielding
Overall Copper Braiding (>85%)

UV Resistance
Yes

RoHS Compliant
Yes

Bending Radius
Min. 10x cable diameter (dynamic)

Drag Chain Suitability
Yes, suitable for continuous flexing in drag chains

Cable Design
Servo Motor Power and Encoder Dual Cable

Cable Category
Motion Control, Drive Technology

Connector Housing
Die-cast zinc, Nickel-plated

Number of Wires
8 (6 power + 2 signal)

Available Lengths
5 m, 10 m, 15 m and custom

About S200 SERVO CABLE 6FX3802-7CD01-1AF0 Dual cable, Preassembled

Dual cable pre-assembled 4x0.75/3x2x0.25 for motor S-1FL2 SH20/30/40 with S200, MOTION-CONNECT 380 Length(m)=5m Dmax power=7.5mm Dmax encoder=7.0mm w.o. brake, Drive End Outlet 5 million bending times

Product lifecycle

Active Product

Product class

A: Standard product which is a stock item could be returned within the returns guidelines/period.

Packaging dimensions (L x W x H)

350.00 x 350.00 x 20.00 mm

Net weight

0.996 Kg

Engineered for Motion Control Systems

The S200 SERVO CABLE is specifically designed for cutting-edge motion control systems and is compatible with Siemens SINAMICS S120 drives and SIMOTICS S motors. With preassembled connectors and dual-cable design, it simplifies complex installations by delivering both power and encoder signals in a single solution. This reduces cabling complexity and boosts operational reliability in automation environments.

Reliability Meets Safety Standards

This cable offers high levels of safety and compliance, boasting UL, CSA, and CE certifications, RoHS compliance, and flame-retardant, halogen-free construction. It withstands oil, UV exposure, high humidity, and operates safely from -25C up to +60C. The robust PUR sheath and copper core contribute to its long service life and mechanical resilience, even under continuous flexing in drag chains.

Versatile, Customizable Installations

Available in standard lengths of 5 m, 10 m, and 15 m, with customizable options to fit unique project requirements, this cable adapts to a variety of layouts. Its preassembled Siemens power and encoder connectors ensure a true plug-and-play experience, minimizing setup time and errors. Its smooth surface and advanced shielding further safeguard data integrity and operational efficiency.

FAQ's of S200 SERVO CABLE 6FX3802-7CD01-1AF0 Dual cable, Preassembled:

Q: How is the S200 SERVO CABLE 6FX3802-7CD01-1AF0 typically installed?

A: The cable is preassembled with Siemens power and encoder connectors, enabling plug-and-play installation. Its flexible PUR outer sheath and drag chain suitability make it easy to route in dynamic, high-motion environments. Simply plug the connectors into compatible SINAMICS S120 drives and SIMOTICS S motors for quick setup.

Q: What makes this cable suitable for drag chain applications?

A: With a minimum dynamic bending radius of 10 times the cable diameter and reinforced by a robust PUR outer sheath and high mechanical protection, the cable is engineered for continuous flexing. Its design resists wear and strain, ensuring reliable performance in drag chain applications over prolonged cycles.

Q: When should I opt for custom cable lengths?

A: Custom lengths are recommended when standard 5 m, 10 m, or 15 m cables do not fit your specific installation needs. Customization ensures optimal cable management and reduces excess slack, preventing potential safety hazards or signal loss in tightly configured automation setups.

Q: Where can this servo cable be deployed?

A: This cable is ideal for industrial environments requiring robust motion control, such as manufacturing lines, robotics, packaging machinery, and material handling systems. Its IP65-rated connectors, UV resistance, and oil/flame resistance make it suitable for both indoor and protected outdoor deployments.

Q: What process ensures signal integrity in this cable?

A: The cable incorporates overall copper braiding with over 85% coverage, shielding both power and encoder wires from electromagnetic interference (EMI). This ensures reliable transfer of power and accurate transmission of encoder signals, critical for precise motion control.

Q: How does the S200 SERVO CABLE benefit my automation system?

A: It reduces installation time, minimizes cabling errors, and improves system reliability through a dual-cable design, preassembled connectors, and superior shielding. Its durable construction ensures longevity, even in harsh industrial environments, delivering both cost-efficiency and consistent performance.
