S200 SERVO CABLE 6FX3802-7CN01-1CA0 Dual cable, Preassembled

Send Inquiry

Request To Call Back

S200 SERVO CABLE 6FX3802-7CN01-1CA0 Dual cable, Preassembled

Name: 6FX3802-7CN01-1CA0 Dual cable, Preassembled
Brand: Emson Power Engineers
Price: 13000 INR
Availability: InStock

Price 13000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

S200 SERVO CABLE 6FX3802-7CN01-1CA0 Dual cable, Preassembled Specification

Insulation Material
PVC/XLPE for cores, PUR for sheath

IP Rating
IP67 with mating connector

Surface Finish
Smooth PUR sheath

Connector Type
Siemens specific preassembled connectors

Shape
Round

Feature
Dual cable for power and signal; preassembled; flexible design

Humidity %
Max. 90% (non-condensing)

Operating Temperature
-30C to +80C

Overheating Protection
No inherent protection; system dependent

Mounting Type
Cable routing

Efficiency
High conductivity, low-loss

Product Type
Dual cable, preassembled

Application
Servo drive systems; connection between Siemens SINAMICS drive and SIMOTICS S motors

Protection Level
For use in industrial environments; shielded

Frequency (MHz)
DC to 10 MHz

Rated Voltage
600 V

Output Type
Power and signal transmission

Color
Black outer sheath

Dimension (L*W*H)
Typically cable diameter ~12 mm; length as specified (customizable, e.g. 10 m)

Weight
Approx. 3.2 kg (for 10 m length)

Input Voltage
600 V max

Phase
Single phase compatible

Size
Cable length as ordered

Material
Copper conductor, PUR outer sheath

No Of Poles
2 + 2 (power + signal pairs)

Connection Type
Preassembled with connectors on both ends

Compatible Devices
SINAMICS S120, SIMOTICS S

Min. Bending Radius
Approx. 7x cable diameter (dynamic), 5x (static)

Packaged Contents
Single preassembled cable with connectors

Flame Retardant
Yes, per IEC 60332-1-2

Oil Resistance
Yes

Manufacturer Part Number
6FX3802-7CN01-1CA0

Shielding
Overall copper braid shielding

Cable Type
Dual hybrid cable (power + signal)

UV Resistant
Yes

Flame Test
Passed per VDE standards

Halogen Free
Yes

Compliance
RoHS compliant

About S200 SERVO CABLE 6FX3802-7CN01-1CA0 Dual cable, Preassembled

Dual cable pre-assembled 4x0.75/2x2x0.25+2x0.38 for motor S-1FL2 SH20/30/40 with S200, MOTION-CONNECT 380 Length(m)=20m Dmax power=7.5mm Dmax encoder=7.0mm w.o. brake, Non Drive End Outle 5 million bending times

Product lifecycle

Active Product

Product class

A: Standard product which is a stock item could be returned within the returns guidelines/period.

Packaging dimensions (L x W x H)

350.00 x 350.00 x 20.00 mm

Net weight

3.36 Kg

Optimal Performance and Protection

The S200 SERVO CABLE (6FX3802-7CN01-1CA0) offers outstanding signal and power integrity for industrial servo drive systems. With overall copper braid shielding, the cable effectively minimizes electromagnetic interference, while its PUR sheath provides resilience against oils, UV rays, and harsh environmental factors. The flame-retardant and halogen-free materials enhance safety and compliance, suitable for demanding manufacturing or automation environments.

Professionally Preassembled and Customizable

This dual hybrid cable is delivered preassembled with Siemens-specific connectors, ensuring rapid, error-free installation. Available in various lengths to fit specific routing requirements, its round, flexible design facilitates easy cabling in confined spaces. The tested quality guarantees reliable connections between SINAMICS S120 drives and SIMOTICS S motors, reducing downtime and simplifying maintenance operations for industrial users.

FAQ's of S200 SERVO CABLE 6FX3802-7CN01-1CA0 Dual cable, Preassembled:

Q: How is the S200 SERVO CABLE 6FX3802-7CN01-1CA0 used in servo systems?

A: This cable is designed for the connection between SINAMICS S120 drives and SIMOTICS S motors, enabling both power and signal transmission in a single flexible hybrid cable. The preassembled connectors ensure quick and secure integration within industrial servo drive configurations.

Q: What benefits does the preassembled design offer for installation?

A: Preassembled Siemens-specific connectors significantly reduce installation time and the risk of wiring errors, ensuring a reliable, plug-and-play connection for industrial applications. This saves both time and labor costs during system setup.

Q: Where can this servo cable be installed?

A: The cable is ideal for use in industrial environments requiring secure, shielded connections. Its oil-resistant, UV-resistant, and flame-retardant PUR sheath provides robust protection, suitable for applications with high mechanical stress and varying ambient conditions.

Q: What safety and compliance certifications does the cable meet?

A: This dual hybrid cable is RoHS compliant, halogen-free, and passes flame retardant tests per IEC 60332-1-2 and VDE standards. It is designed to provide safe operation in demanding settings.

Q: What is the process for customizing cable length?

A: Cable lengths can be specified at the time of ordering to suit diverse installation requirements. Manufacturers and authorized distributors in India typically offer this option to ensure optimal fit for system layouts.

Q: How does the cable benefit signal integrity and system efficiency?

A: Overall copper braid shielding ensures reliable electromagnetic protection, while the high-conductivity copper conductors and smooth PUR sheath minimize signal loss and maximize transmission efficiency between drive and motor.

Tell us about your requirement
