6SL5610-1BB10-8AA0 SINAMICS S200 BasicPTI,1/3AC200V 0.75kW

Name: 6SL5610-1BB10-8AA0 SINAMICS S200 BasicPTI,1/3AC200V 0.75kW
Brand: Emson Power Engineers
Price: 19500 INR
Availability: InStock

Price 19500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

6SL5610-1BB10-8AA0 SINAMICS S200 BasicPTI,1/3AC200V 0.75kW Specification

Surface Finish
Matt

Mounting Type
Panel Mount

Humidity %
<90% (non-condensing)

Insulation Material
High grade plastic insulation

IP Rating
IP20

Feature
Fieldbus communication, integrated brake chopper

Shape
Rectangular

Overheating Protection
Yes, via monitoring circuit

Power Factor
>0.94

Efficiency
High efficiency, >95%

Connector Type
Plug-in/Screw type

Operating Temperature
0C to +40C (without derating)

Product Type
AC Drive (Servo Converter)

Application
Industrial automation, motion control, CNC machinery

Protection Level
Overvoltage, overload, short circuit

Frequency (MHz)
50/60 Hz

Rated Voltage
200 - 230 V AC

Energy Consumption
Optimized for low-loss operation

Output Type
3-phase motor output

Color
Grey

Dimension (L*W*H)
60 x 170 x 181 mm

Weight
1.4 kg

Phase
Single/Three Phase

Size
Standard compact

Input Voltage
200 - 230 V AC, 1/3 Phase

Material
Plastic, Metal

Connection Type
Screw terminal

Communication Interface
RS485 (Modbus RTU, USS)

Supply Frequency
47-63 Hz

Display
Status LEDs

Noise Level
<65 dB(A)

Storage Temperature
-25C to +70C

Relative Altitude
1000 m without derating

Motor Output Power
0.75 kW (1 HP)

Braking Module
Integrated

Cooling Method
Forced air cooling, internal fan

Control Method
V/F, Vector Control

About 6SL5610-1BB10-8AA0 SINAMICS S200 BasicPTI,1/3AC200V 0.75kW

SINAMICS S200 Basic, with Pulse Input voltage: 200-240 V 1/3 AC; -15%/+10%; 50/60Hz; Output voltage: 0-inpu 4.4A; 0-550Hz; Motor: 0.75kW Degree of protection: IP20 FSC, 60x170x195 (WxHxD)

Flexible Drive Solution for Modern Automation

The SINAMICS S200 BasicPTI is specifically crafted for a broad range of industrial applications, offering seamless integration into automation and motion control systems. Its compact, panel-mount form factor, combined with high efficiency and multiple phase compatibility, ensures straightforward installation and operation. Enhanced by connectivity options and protective features, users benefit from reliable, uninterrupted performance in demanding environments.

Integrated Protection and Efficient Performance

This drive includes an array of protective measures such as derating-free operation up to 40C, overvoltage, overload, and short circuit safeguards, as well as advanced overheating protection. Its integrated brake chopper and optimized energy consumption minimize losses, leading to superior overall efficiency. The robust IP20-rated enclosure assures safe operation within harsh industrial settings.

FAQ's of 6SL5610-1BB10-8AA0 SINAMICS S200 BasicPTI,1/3AC200V 0.75kW:

Q: How is the SINAMICS S200 BasicPTI typically installed and connected?

A: The SINAMICS S200 BasicPTI is designed for easy panel mounting using its compact rectangular form. Electrical connections are made via standard screw terminals or plug-in connectors, accommodating both single and three-phase input, and supplying a three-phase motor output.

Q: What control methods are supported by this inverter, and how do they benefit applications?

A: This inverter supports both V/F (Voltage/Frequency) and Vector control methods. V/F control offers simple speed regulation for standard motors, while Vector control provides precise torque and speed management, ideal for applications like CNC machinery and motion control.

Q: When should I use the integrated braking module, and what advantage does it provide?

A: The integrated braking module is used when rapid deceleration of the motor is required, particularly in applications with frequent stops or heavy loads. It enhances application safety and efficiency by dissipating excess energy during braking, preventing system overvoltage.

Q: Where can the SINAMICS S200 BasicPTI operate without performance derating?

A: This device can operate at full performance without derating at altitudes up to 1000 meters above sea level and within ambient temperatures of 0C to +40C. This ensures it is suitable for most indoor industrial locations in India and globally.

Q: What communication interfaces are available, and how do they facilitate integration?

A: The unit features an RS485 communication port supporting Modbus RTU and USS protocols. This enables straightforward integration with various fieldbus systems, PLCs, and remote control units, making it ideal for modern factory automation setups.

Q: How does the SINAMICS S200 ensure high operational efficiency and protect against overheating?

A: Engineered with high-grade materials and optimized for low-loss operation, the SINAMICS S200 boasts an efficiency above 95%. Overheating is actively prevented through a forced air cooling system with an internal fan and a dedicated monitoring circuit for thermal protection.
