Cable Junction Boxes IP 66/67 with PE Inlay

Name: Cable Junction Boxes IP 66/67 with PE Inlay
Brand: Emson Power Engineers
Price: 2040.0 INR
Availability: InStock

Price 2040.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66/67 with PE Inlay Specification

Surface Finish
Smooth/Matte

Feature
Waterproof, Dustproof, UV Resistant, Flame Retardant

IP Rating
IP66/IP67

Humidity %
up to 95% RH (non-condensing)

Operating Temperature
-20C to +85C

Efficiency
High, >98%

Overheating Protection
YES

Shape
Rectangular

Mounting Type
Wall/Surface Mount

Connector Type
Screw Connectors

Insulation Material
Polyethylene (PE) Inlay

Product Type
Cable Junction Box

Application
Outdoor and indoor cable connection and distribution

Protection Level
IP66/IP67

Frequency (MHz)
50/60 Hz

Rated Voltage
up to 500V AC

Output Type
Terminal Block

Color
Light Grey (RAL 7035)

Dimension (L*W*H)
160 mm x 120 mm x 75 mm

Weight
5 Kilograms (kg)

Input Voltage
up to 500V AC

Phase
PHASE-3

Size
130X130X77

No Of Poles
2/3/4/5 pole options available

Material
Polycarbonate with PE inlay

Connection Type
Screw Terminal

Flame Resistance
UL94 V-0

Service Life
Over 10 years

Terminal Capacity
up to 2.5 mm2

UV Resistance
Yes, suitable for outdoor installation

Impact Resistance
IK08

Cable Entry
Up to 6 x M20 cable glands (not included)

Lid Fixing
4 captive stainless steel screws

Gasket Type
Injected PU gasket

Cable Junction Boxes IP 66/67 with PE Inlay Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66/67 with PE Inlay

Pick Yours now and experience the redoubtable strength of our Cable Junction Boxes IP 66/67 with potent PE inlay for uncompromising outdoor and indoor cable distribution. Offering affordable reliability, each box is manufactured from robust polycarbonate with a resilient PE inlay, soaring above competitors in UV and flame resistance (UL94 V-0). With a service life soaring over 10 years and high-impact IK08 protection, these boxes are engineered for professional durability. Get seamless installation and adaptability, supporting up to 6 M20 cable glands. Choose from 2/3/4/5 pole variants to perfectly match your needs-Get the assurance of waterproof, dustproof performance and safeguard your connections under harsh environments now.

Superior Material and Flexible Installation

These IP 66/67 Cable Junction Boxes are meticulously constructed from light grey polycarbonate material with a PE inlay, enhancing both flame and UV resistance. The boxes are designed for easy wall or surface mounting, with screw terminal connections for secure fitting. Each unit comes with four captive stainless steel lid screws and an injected PU gasket, ensuring a potent waterproof seal. Ideal for both indoor and outdoor cable connections, these boxes efficiently support multiple pole options for varied applications.

Certified Safety and Streamlined Packaging

Every box meets high-performance certifications such as UL94 V-0 and boasts robust overheating protection. Our sample policy ensures that you can review the product quality before bulk orders. Packaging is thoughtfully done to safeguard your purchase during express shipping, ensuring a smooth unboxing experience. With a competitive sale price for distributors and bulk buyers in India, you get value alongside certified safety and fast, reliable delivery.

FAQ's of Cable Junction Boxes IP 66/67 with PE Inlay:

Q: How does the PE inlay enhance the protection of the Cable Junction Boxes?

A: The PE inlay provides additional electrical insulation, improves impact resistance, and increases the junction box's longevity-even in harsh outdoor environments.

Q: What application method should be followed for installing these boxes?

A: Mount the box using its wall/surface mounting features, connect cables through up to six M20 glands, and secure the lid with the four captive stainless steel screws for optimal weatherproofing.

Q: When is the best time to use these IP66/IP67 junction boxes?

A: These boxes are ideal for use whenever you require robust, waterproof, dustproof, and UV-resistant connection or distribution-especially in demanding outdoor or industrial environments.

Q: Where can I deploy these junction boxes safely?

A: The boxes are suitable for both indoor and outdoor installations, including factories, commercial premises, residential complexes, and outdoor electrical panels.

Q: What is the process for customizing pole options and order quantities?

A: Contact the distributor or supplier to specify the required number of poles (2, 3, 4, or 5) and your preferred order quantity. Sample policies may apply for bulk orders.

Q: What benefit does the IP66/IP67 rating provide?

A: The IP66/IP67 rating ensures the junction box is highly protected against dust, strong water jets, and temporary immersion, making it ideal for extreme environments.
