Cable Junction Boxes IP 66 (Grey) with integrated membranes

Send Inquiry

Request To Call Back

Cable Junction Boxes IP 66 (Grey) with integrated membranes

Name: Cable Junction Boxes IP 66 (Grey) with integrated membranes
Brand: Emson Power Engineers
Price: 370.0 INR
Availability: InStock

Price 370.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66 (Grey) with integrated membranes Specification

IP Rating
IP66

Overheating Protection
NO

Efficiency
Passive device

Humidity %
Up to 95% (Non-condensing)

Shape
Rectangular

Insulation Material
Polycarbonate

Feature
Integrated cable entry membranes, halogen free, maintenance free

Surface Finish
Matte/UV resistant

Mounting Type
Surface mounting/Wall mounting

Connector Type
Integrated Membrane Cable Entries

Operating Temperature
-25C to +40C

Product Type
Cable Junction Box

Application
Electrical cable management and connections

Protection Level
Weatherproof, dust tight

Frequency (MHz)
50/60 Hz

Rated Voltage
230/400 V AC

Energy Consumption
Passive/Not Applicable

Output Type
Terminal blocks

Color
Grey

Dimension (L*W*H)
110 mm x 110 mm x 66 mm

Weight
5 Kilograms (kg)

Phase
Single Phase

Input Voltage
230/400 V AC

Size
Medium (other sizes available)

Material
Polycarbonate (PC)

Connection Type
Screw/Push-In Terminal

No Of Poles
Single

Service Life
>10 years under normal conditions

Ingress Type
Membrane with self-sealing entry

Ambient Storage Temperature
-25C to +80C

Cover Fastening
Captive stainless steel screws

Impact Resistance
IK07

UV Resistance
Yes, suitable for outdoor installations

Halogen Free
Yes

Number of Cable Entries
5 Side + 1 Rear

Flame Retardancy
UL 94 V-2

Installation Instruction
Tool-free membrane cable insertion

Cable Entry Sizes
Up to 5 x 16 mm integrated membrane entries

Gasket Material
EPDM rubber

Cable Junction Boxes IP 66 (Grey) with integrated membranes Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66 (Grey) with integrated membranes

Take advantage of an unassailable deal with our Cable Junction Boxes IP66 (Grey) featuring integrated membranes. Engineered for stellar performance, these superlative boxes cater to both indoor and outdoor installations with 5 side and 1 rear cable entries, suiting up to 5 x 16 mm cable sizes. The polycarbonate enclosure ensures weatherproof, dust-tight protection, while captive stainless steel screws deliver robust cover fastening. UV resistance, flame retardancy (UL 94 V-2), and halogen-free construction guarantee long-term durability. Integrated EPDM membranes promise ultra-secure, tool-free cable insertion. A preferred solution for distributors, manufacturers, and suppliers across India, offering maintenance-free, passive, and efficient electrical connections. Secure your featured connection box today!

Exceptional Features and User Applications

These medium-sized IP66 cable junction boxes offer extra features such as UV resistance, halogen-free composition, captive stainless steel screws, and a matte, maintenance-free finish. Used extensively by electrical contractors, OEMs, and facility managers, they provide superior cable management in both 3-phase and single-phase installations. Notably, the self-sealing membrane entries and high impact resistance (IK07) deliver reliable protection and ease of use, making them ideal for demanding environments where safety, reliability, and longevity are paramount.

Sample Availability and Order Process

Samples of the cable junction boxes are available upon request to help evaluate suitability for your applications. Our FOB port is typically located in major Indian cities, facilitating smooth export transactions. Once the purchase order and proposal amount are confirmed, we ensure quick dispatch and dependable delivery times (usually within 7-10 working days). Our prompt logistics make these IP66 junction boxes an attractive option for both urgent projects and planned installations.

FAQ's of Cable Junction Boxes IP 66 (Grey) with integrated membranes:

Q: How does the integrated membrane system benefit cable installations?

A: The integrated membrane system allows for self-sealing cable entries, ensuring quick, tool-free installation while maintaining IP66 weatherproof and dust-tight protection. This feature minimizes downtime and maximizes sealing integrity.

Q: What applications are these IP66 cable junction boxes suitable for?

A: These junction boxes are ideal for both indoor and outdoor electrical connections, including industrial automation, building infrastructure, power distribution, and facility management, due to their rugged, weather-resistant construction.

Q: Where can I purchase or request samples of these junction boxes in India?

A: You can easily request samples or place a purchase order through authorized distributors, manufacturers, suppliers, or traders of electrical equipment in India. Samples are provided for product evaluation.

Q: What is the process for installing cables into these junction boxes?

A: Installation is simple: cables are pushed through the integrated membrane entries, which self-seal around the cable. No special tools are required, streamlining the setup and ensuring long-term protection.

Q: What makes these junction boxes a featured choice for service providers?

A: Their superior UV resistance, halogen-free material, high impact resistance, and maintenance-free design make them a preferred solution for service providers who demand longevity and reliable environmental sealing.
