Siemens 6ES7 288-3AM03-0AA0

Price 11656.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens 6ES7 288-3AM03-0AA0 Specification

Connector Type
Screw Type Terminal Block

Insulation Material
Polycarbonate

Shape
Rectangular

Surface Finish
Matte

Mounting Type
DIN Rail Mounting

Feature
8 AI (analog input) channels, 0-10 V input range

Humidity %
5% to 95%, non-condensing

Overheating Protection
Electronic Protection

Operating Temperature
0 to 55C

IP Rating
IP20

Efficiency
High, suitable for continuous industrial use

Product Type
Expansion Module (Analog Input)

Application
Industrial Automation, S7-200 SMART System Integration

Protection Level
Overvoltage & Short Circuit Protected

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
Max. 2.4 W

Output Type
Analog Input

Color
Grey

Dimension (L*W*H)
90 x 60 x 36 mm

Weight
Approx. 190 g

Input Voltage
24 V DC

Size
Compact

Phase
Single Phase

Connection Type
Screw Terminal

Material
Plastic, Metal Components

Response Time
Typical 1 ms

Number of Analog Inputs
8 Channels

Vibration Resistance
2 g, 10-500 Hz

Isolation
Channel to PLC 500 V AC, 1 min

Resolution
12 bits

Series
S7-200 SMART

Installation Position
Any

Storage Temperature
-40° to 70°C

LED Indicators
Status Indication Available

Input Signal Type
0-10 V DC (Analog)

Siemens 6ES7 288-3AM03-0AA0 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
4 Week

About Siemens 6ES7 288-3AM03-0AA0

Manufacturer Series	6ES7 288-3AM03-0AA0
Brand	siemens
Mounting Type	Panel Mount
Output Type	Analog
Usage/Application	Automation
Country of Origin	Made in India
Availability	In Stock

Precision Analog Input for Industrial Automation

The S7-200 SMART analog input module provides 8 channels of high-resolution (12-bit) analog input, designed for accurate reading of 0-10 V DC signals from a variety of industrial sensors. It ensures reliable data acquisition for process control and monitoring applications.

Rugged and Versatile Design for Continuous Use

Built with a robust polycarbonate and metal construction, this module withstands harsh conditions such as vibrations (up to 2g), wide temperature (-40 to 70C storage), and fluctuating humidity, making it ideal for continuous industrial use. Electronic and mechanical protections guarantee dependable operation.

Simple Integration with S7-200 SMART Systems

Engineered for seamless integration with Siemens S7-200 SMART PLCs, this compact module is easily mounted on DIN rails and features clear LED indicators for real-time status. Its convenient screw terminal connections streamline installation and servicing processes.

FAQ's of Siemens 6ES7 288-3AM03-0AA0:

Q: How do I install the Siemens 6ES7 288-3AM03-0AA0 analog input module in my control panel?

A: This module is designed for DIN rail mounting in any installation position. Simply attach it to the rail, connect the 24 V DC power supply, and wire sensor signals into the screw-type terminal block following the manufacturer's guidelines for secure and reliable operation.

Q: What steps should be followed to configure and use the module's 8 analog input channels?

A: After physical installation, connect your 0-10 V DC signals to the analog input channels. Within the S7-200 SMART PLC programming environment, assign the analog inputs and set required parameters, ensuring you match each channel to its corresponding field device.

Q: When is this module most beneficial in industrial automation applications?

A: It excels in scenarios that demand high-speed, precise analog data acquisition from multiple sensors-such as process monitoring, manufacturing automation, and environmental measurement-thanks to its fast 1 ms typical response time and 12-bit measurement resolution.

Q: Where can I use this module considering environmental and physical conditions?

A: With an IP20 rating and resistance to 2g vibration across a range of 10-500 Hz, this module is suitable for indoor industrial environments where dust and moisture levels are controlled (5%-95% non-condensing humidity), and temperatures range from 0C to 55C during operation.

Q: What features ensure the safety and protection of the analog input module and the PLC system?

A: The module incorporates 500 V AC isolation between channels and the PLC, overvoltage and short-circuit protection, as well as electronic overheating protection. These features safeguard both the module and the connected automation system even in challenging working conditions.

Q: How does the status indication via LED indicators benefit users during operation or troubleshooting?

A: Front-panel LED indicators display real-time channel and system status, enabling quick identification of operating conditions or faults. This facilitates prompt maintenance and efficient troubleshooting without the need for specialized diagnostic equipment.

Q: What makes this module efficient and cost-effective for industrial automation projects in India?

A: Its compact size, low energy consumption (max. 2.4 W), and ease of integration with S7-200 SMART PLCs enable efficient control system design. Local availability through distributors, suppliers, and service providers adds further value by ensuring quick support and accessibility.
