siemens 6SL3210-1PE13-2UL1

Name: siemens 6SL3210-1PE13-2UL1
Brand: Emson Power Engineers
Price: 11998.0 INR
Availability: InStock

Price 11998.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

siemens 6SL3210-1PE13-2UL1 Specification

Surface Finish
Matte

Shape
Rectangular

Overheating Protection
YES

Connector Type
Screw

IP Rating
IP20

Power Factor
>0.95

Feature
Simple Commissioning, Integrated Braking Chopper, Robust Design

Efficiency
>96%

Mounting Type
Panel Mount

Insulation Material
Plastic

Operating Temperature
-10C to +60C

Humidity %
<95% (non-condensing)

Product Type
SINAMICS V20 AC Drive

Application
Industrial Automation, Motor Control, HVAC Systems, Pumps, Fans

Protection Level
Overload, Short Circuit, Overvoltage, Undervoltage

Frequency (MHz)
50/60 Hz

Rated Voltage
380-480 V AC

Energy Consumption
High Efficiency

Output Type
Analog / Digital

Color
Grey

Dimension (L*W*H)
184 x 100 x 170 mm

Weight
3.5 kg

Size
132 F

Phase
Three Phase

Input Voltage
380-480 V AC

No Of Poles
3

Connection Type
Screw Terminal

Material
Plastic, Metal

Model Number
6SL3210-1PE13-2UL1

Output Power
1.5 kW (2 HP)

Input Phase
Three Phase

Storage Temperature
-40°C to +70°C

Motor Type Supported
Asynchronous (Induction)

Standards Complied
IEC/EN 61800-5-1

Digital Inputs
4

Cooling
Fan Cooled

Braking Chopper
Integrated

Communication Ports
RS485

Relay Outputs
1

EMC Filter
Integrated

Maximum Altitude
1000 m (without derating)

Analog Inputs
1

Display Type
LED Display

Control Method
V/f Control

Output Current
3.7 A

siemens 6SL3210-1PE13-2UL1 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
4 Week

About siemens 6SL3210-1PE13-2UL1

Motor Power	7.5kW
Enclosure Type	IP20
Control Method	V/F Control
Communication Interface	Ethernet
Net Weight (kg)	1,380 Kg
Packaging Dimension	90,00 x 185,00 x 280,00
Availability	In Stock

SINAMICS Power Module PM240-2 unfiltered with integrated braking chopper 380-480 V 3 AC +10/-10% 47-63 Hz Power high overload: 0.75kW at 200% 3s, 150% 57s, 100% 240 s; Ambient temperature -10 to +50 C; power low overload: 1.1kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature -10 to +40 C 196x 73x 165 (HxWxD), FSA Degree of protection IP20 without Control Unit and operating unit Released as of CU firmware version V4.

Simple Commissioning & Robust Performance

The Siemens 6SL3210-1PE13-2UL1 features a user-focused design, enabling straightforward commissioning and ease of integration into existing systems. With built-in protections against overload, short circuit, overvoltage, and undervoltage, it ensures reliable performance under demanding industrial conditions.

Highly Efficient Motor Control

Benefit from high energy efficiency (>96%) and precise V/f control, making this drive a perfect choice for industrial automation, HVAC, pump, and fan applications. The integrated braking chopper and advanced cooling (fan-cooled) further optimize performance and longevity.

Integrated Communication and Flexibility

Equipped with RS485 communication, four digital inputs, an analog input, and a relay output, this drive offers versatile connectivity and control options. Its panel-mount form and IP20 protection rating allow flexible and secure installation in varied environments.

FAQ's of siemens 6SL3210-1PE13-2UL1:

Q: How do I install the Siemens 6SL3210-1PE13-2UL1 variable frequency drive?

A: To install the 6SL3210-1PE13-2UL1, securely mount it onto a panel using the provided screw terminals. Ensure connection to a three-phase 380-480 V AC supply and connect your asynchronous motor. Follow all safety standards and guidelines per IEC/EN 61800-5-1 during installation.

Q: What types of motors are supported by this drive?

A: This Siemens drive is designed to control asynchronous (induction) motors, making it suitable for a wide range of industrial automation, HVAC, pump, and fan systems.

Q: Where can the 6SL3210-1PE13-2UL1 be used?

A: It is ideal for use in industrial automation, HVAC systems, pump controls, and fan operations across manufacturing plants, commercial buildings, and process industries. Its robust design ensures reliable function even in challenging environments.

Q: What protections does this drive offer?

A: The unit includes comprehensive protection mechanisms-overload, short circuit, overvoltage, undervoltage, and overheating protection-to ensure operational safety and longevity of both the drive and connected motors.

Q: How does the integrated braking chopper benefit my application?

A: The built-in braking chopper dissipates excess energy during rapid braking operations, allowing for controlled stopping of motors and enhanced safety, especially in high-inertia applications like fans and conveyor systems.

Q: What are the environmental operating limits for this model?

A: The drive operates reliably from -10C to +60C and can be stored at temperatures between -40C and +70C. It is suitable for installation up to 1000 m altitude without derating, and can handle humidity below 95% (non-condensing).
