SIEMENS LOGO MODULE

Name: SIEMENS LOGO MODULE
Brand: Emson Power Engineers
Price: 4500.0 INR
Availability: InStock

Price 4500.0 INR/ Set

Get a Price/Quote

MOQ : 1 Piece

SIEMENS LOGO MODULE Specification

Humidity %
Max. 95% RH, non-condensing

Surface Finish
Matte

Feature
Expandable, Easy wiring, High reliability

Operating Temperature
-20 C to +55 C Celsius (oC)

Power Factor
High

Overheating Protection
YES

Mounting Type
DIN Rail

IP Rating
IP20

Shape
Rectangular Module

Efficiency
>95%

Connector Type
Pluggable Screw Terminals

Insulation Material
Polycarbonate (PC)

Product Type
Relay Expansion Module

Application
Industrial Automation, Control Panel Expansion

Protection Level
IP54

Frequency (MHz)
50/60 Hz Hertz (HZ)

Rated Voltage
24 V DC Volt (V)

Energy Consumption
Low Kilowatt-hour ( KWH)

Output Type
Relay (NO/NC contacts)

Color
Grey

Dimension (L*W*H)
90 mm x 35 mm x 58 mm (approx.) Centimeter (cm)

Weight
105 g (approx.) Grams (g)

Warranty
12 MONTHS FROM THE DATE OF INVOICE

Size
Compact

Phase
Single Phase

Input Voltage
24 V DC Volt (V)

Connection Type
Screw terminals

No Of Poles
8 channels (Relay Output Module)

Material
Plastic, Electronic components

Current per Output
10 A

Shock Resistance
Acc. to EN 60068-2-27

Standards Compliance
CE, UL, cULus, EAC, CSA

Number of Outputs
8 relay outputs (Each 10A at 250V AC/30V DC)

Vibration Resistance
Acc. to EN 60068-2-6

Maintenance
Maintenance-free

Series
LOGO! 8 DM8 24R

Suitable for LOGO! Base Modules
yes, for LOGO! 8 24V base module

Service Life (Relay Contacts)
100,000 operations (nominal)

Response Time
<10 ms

Part Number
6ED1 055-1CB00-0BA2

Wiring Type
Solid or flexible wire, 0.52.5 mm

SIEMENS LOGO MODULE Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Days

About SIEMENS LOGO MODULE

LOGO! DM8 24 expansion module, PS/I/O: 24V/24V/trans., 4 DI/4 DO for LOGO! 8

Sustainability

Product lifecycle

Active Product

Product class

A: Standard product which is a stock item could be returned within the returns guidelines/period.

Packaging dimensions (L x W x H)

9,6 x 7,00 x 5,5 cm

Net weight

0,129 Kg

Versatile Expansion for LOGO! 8 Systems

Easily expand your LOGO! 8 24V base module with 8 relay outputs using the SIEMENS LOGO! 6ED1 055-1CB00-0BA2. This compact, DIN rail-mountable module allows seamless integration into industrial control panels, supporting both solid and flexible wiring. It's engineered for high efficiency and reliable performance, making it suitable for a variety of automation tasks where robust relay operation is required.

Reliable Performance and Durability

This LOGO! module delivers consistent performance even under demanding industrial environments. With shock and vibration resistances conforming to EN 60068 standards, plus an operating temperature range from -20C to +55C and up to 100,000 relay operations, longevity is assured. The matte-finished polycarbonate housing supplements its rugged design, and IP54-rated protection ensures resilience against dust and humidity.

FAQ's of SIEMENS LOGO MODULE :

Q: How do I install the SIEMENS LOGO! 8 DM8 24R expansion module?

A: This module is designed for simple DIN rail mounting and is connected through pluggable screw terminals. Wiring is compatible with solid or flexible wire (0.5-2.5 mm2). Ensure it's paired with a LOGO! 8 24V base module for seamless operation.

Q: What are the main benefits of using this module in control panel applications?

A: It offers 8 high-capacity relay outputs (10A each), enabling you to control diverse loads. Maintenance-free and expandable, the module ensures rapid response and long service life (up to 100,000 operations), with protection against overheating and environmental factors.

Q: When is the SIEMENS LOGO! expansion module best suited for use?

A: This expansion module is ideal for industrial automation or wherever additional relay outputs are required. It excels in environments requiring rugged reliability, fast switching, and compact design, such as control panels or process machinery.

Q: Where can I use the LOGO! 8 DM8 24R module within an automation system?

A: This expansion module integrates directly with LOGO! 8 24V base modules, fitting into industrial control panels, distribution boxes, and any installation that requires additional relay outputs for control or monitoring.

Q: What process is involved in wiring and configuring the module?

A: Connect each output channel via pluggable screw terminals, supporting solid or flexible wiring. Once securely mounted and wired, configure your LOGO! logic controller to address and utilize the new relay outputs per your application needs.

Q: What makes the SIEMENS LOGO! module reliable for industrial use?

A: With certifications like CE, UL, and CSA, robust anti-shock/vibration construction, IP54/IP20 protection, and a high operating efficiency (>95%), the module is built for dependable, long-term use in challenging settings.
