SIMATIC ET 200SP 6ES7135-6HB00-0DA1

Price 22000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIMATIC ET 200SP 6ES7135-6HB00-0DA1 Specification

Operating Temperature
-30C to +60C

Insulation Material
Plastic

Efficiency
High signal accuracy

Shape
Rectangular

Overheating Protection
YES

IP Rating
IP20

Surface Finish
Matte

Humidity %
5% 95% (non-condensing)

Connector Type
Push-in terminal

Mounting Type
DIN Rail

Feature
Hot swapping; Channel diagnostics; LED indication; Parameterizable

Product Type
I/O Module (AI 2xU/I/RTD/TC 16 Bit Standard) with Diagnostics

Application
Industrial Automation, ET 200SP Distributed I/O System

Protection Level
Short-circuit and overload protection

Frequency (MHz)
DC or frequency independent

Rated Voltage
24 V DC

Energy Consumption
0.6 W

Output Type
Analog Input

Color
Grey

Dimension (L*W*H)
73 x 15 x 58 mm

Weight
30 g

Input Voltage
24 V DC

Size
Standard ET 200SP

Material
Plastic, Metal

Connection Type
Terminal Block, Push-in

Resolution
16 bit

Number of Channels
2 (for voltage, current, RTD, thermocouples)

PT100/1000, Thermocouple Support
Yes (RTD/TC type configurable)

Group Code
AI 2xU/I/RTD/TC 16 bit standard

SIMATIC Series
ET 200SP

Diagnostics
Channel-specific diagnostics, wire break detection, overrange and underrange detection

Voltage Input Range
±10 V

Relative Humidity (Operation)
Up to 95% (non-condensing)

Current Input Range
0/4 to 20 mA

Product Lifecycle
Active

Siemens Article Number
6ES7135-6HB00-0DA1

SIMATIC ET 200SP 6ES7135-6HB00-0DA1 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
4 Week

About SIMATIC ET 200SP 6ES7135-6HB00-0DA1

Output Type	Analog
Brand	SIEMENS
Manufacturer Series	6ES7135-6HB00-0DA1
Mounting Type	Wall Mount
Usage/Application	Automation
Model No.	6ES7135-6HB00-0DA1
Availability	In Stock
View in Hindi	200 6ES7135-6HB00-0DA1

SIMATIC ET 200SP, Analog output module, AQ 2x U/I High Speed, suitable for BU type A0, A1, Color code CC00, channel diagnostics, 16 bit, +/-0.2%

Versatile Analog Input Capabilities

The SIMATIC ET 200SP AI module accommodates a range of analog signals, including voltage, current, resistance temperature detectors (RTD), and thermocouples. With channel-specific configuration, each input can be tailored to precise industrial sensing needs, boosting flexibility for automation tasks.

Comprehensive Diagnostics and Protection

Advanced diagnostic features such as channel-specific fault detection, wire break indicators, and overrange/underrange alerts ensure operational reliability. The module supports short-circuit and overload protection, safeguarding both the device and the connected equipment from damage during active use.

Hassle-Free Installation and Maintenance

Installation is effortless thanks to its lightweight design, standard ET 200SP size, and push-in terminal connections. Hot-swapping capabilities allow engineers to replace or upgrade the module without interrupting plant operations, which minimizes downtime and maintenance disruption.

FAQ's of SIMATIC ET 200SP 6ES7135-6HB00-0DA1:

Q: How can I configure the input channels of the SIMATIC ET 200SP 6ES7135-6HB00-0DA1 for different sensor types?

A: The input channels are individually parameterizable via the automation system's software. You can configure each channel to accept voltage, current, RTD, or thermocouple inputs, enabling seamless adaptation to your specific sensing requirements.

Q: What diagnostics features does this analog input module provide?

A: It offers channel-specific diagnostics, including wire break, overrange, and underrange detection. These features can be monitored directly via the control system or through LED indicators, ensuring prompt notification of any channel abnormality.

Q: When is hot swapping possible, and what benefits does it bring?

A: Hot swapping is supported at any time during standard operation, provided safety protocols are followed. This process allows for module replacement or maintenance without shutting down the entire system, minimizing operational interruptions.

Q: Where is the SIMATIC ET 200SP 6ES7135-6HB00-0DA1 typically installed?

A: This module is designed for mounting on DIN rails within industrial automation panels, specifically as part of the ET 200SP distributed I/O system, making it ideal for decentralized control applications in factories and process plants.

Q: What is the process for connecting and securing signal wires to this module?

A: Signal wires are connected using push-in terminal blocks, facilitating quick and reliable wiring. The modular design ensures secure connectivity and ease of maintenance, while matte-finished insulation material enhances durability.

Q: How does this module protect against environmental and operational risks?

A: The unit features IP20 protection, short-circuit and overload safeguards, as well as operational resilience from -30C to +60C and high humidity levels (up to 95% non-condensing), making it robust for a wide range of industrial settings.

Q: What are the primary benefits of using this module in an automation setup?

A: Key advantages include high signal accuracy across various analog input types, comprehensive diagnostics, minimal downtimes thanks to hot-swapping, and flexible configuration options, all contributing to improved efficiency and reliability in industrial automation.
