Two component gel

Name: Two component gel
Brand: Emson Power Engineers
Price: 7080.0 INR
Availability: InStock

Price 7080.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Two component gel Specification

Efficiency
99% Insulation Efficiency

IP Rating
IP68

Surface Finish
Smooth

Mounting Type
Pour-in Cavity/Encapsulation

Operating Temperature
-40C to +110C

Connector Type
Compatible with Most Cable Connectors

Feature
Fast Curing, Water Resistant, Flexible after Curing

Humidity %
Max 98% Relative Humidity

Shape
Rectangular

Insulation Material
Silicone-based Gel

Power Factor
0.95

Overheating Protection
Thermal Dissipation Properties

Product Type
Insulating Gel Kit

Application
Electrical Cable Jointing and Insulation

Protection Level
High Dielectric Strength

Frequency (MHz)
50/60

Rated Voltage
Up to 1 kV

Output Type
Insulating Compound

Color
Transparent

Dimension (L*W*H)
210 mm x 120 mm x 70 mm

Weight
2 Kilograms (kg)

Size
Standard Kit (Can fill up to 1.5 L)

Phase
PHASE 3

Input Voltage
Up to 1 kV

No Of Poles
2

Connection Type
Pour-in-Place

Material
Silicone Gel (Two Component)

Shelf Life
18 Months (unopened)

Packaging Type
Dual Component Sachets with Mixing Bag

Dielectric Strength
>23 kV/mm

UV Stability
Yes

Flammability
Non-flammable

Storage Conditions
Store in a cool, dry place

Mixing Ratio
1:1 (A:B Components)

Cure Time
~10 Minutes at 25C

Toxicity
Non-toxic, RoHS Compliant

Two component gel Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Two component gel

Set sealing compound, 500 ml
for WP 040x x
sealing compound for refilling after changes or repairs
durability of sealing compound to processing 12 months at a storage temperature of 5 - 50 C

Superior Electrical Insulation and Protection

Engineered for modern electrical cable jointing and insulation, this two-component silicone gel delivers exceptional dielectric strength and protection. Its IP68 rating guarantees resistance to water and environmental contaminants, offering reliable insulation even in harsh conditions. The transparent, flexible finish allows for easy inspection and long-term durability, ensuring cables remain fully protected-from industrial sites to residential installations.

Effortless Application with Quick Cure Time

Designed for efficiency, the gel uses a straightforward 1:1 component mixing ratio, paired with a convenient pour-in-place system. Each kit includes dual sachets and a mixing bag, streamlining preparation and application. Once mixed and poured, the gel cures in approximately 10 minutes at room temperature, enabling rapid project completion without sacrificing quality or protection.

Safe, Compliant, and Versatile

Safety is paramount with this non-toxic, RoHS-compliant, and non-flammable formulation. Its UV stability, wide operating temperature range, and compatibility with most cable connectors make it suitable for use in diverse environments. The gel's thermal dissipation and anti-overheating characteristics foster longer-lasting connections and reduce maintenance needs.

FAQ's of Two component gel:

Q: How do I properly mix and apply the two-component silicone gel?

A: Combine equal parts of Components A and B (1:1 ratio) in the provided mixing bag. Mix thoroughly until you achieve a consistent, homogenous gel. Pour the mixture directly into the prepared cable joint cavity or mold. The gel will set and cure within about 10 minutes at 25C.

Q: What are the main benefits of using this gel for electrical cable jointing?

A: This gel offers high dielectric strength (>23 kV/mm), exceptional insulation efficiency (99%), water resistance, UV stability, and flexibility after curing. It also protects against moisture, dust, and overheating-making it ideal for reliable long-term cable insulation.

Q: When should I use this gel in my electrical installations?

A: Use this gel whenever you require secure and durable insulation for cable joints, especially where high protection and fast curing are vital. It is suited for environments demanding IP68-level sealing, high humidity, and a wide temperature range.

Q: Where can I store the unopened sachets for maximum shelf life?

A: Store the unopened dual-component sachets in a cool, dry place to maintain their 18-month shelf life. Avoid exposure to direct sunlight, excessive heat, or moisture to preserve the product's effectiveness.

Q: What is the process for encapsulating a cable joint with this gel?

A: Prepare the cable joint, mix Components A and B as instructed, and pour the blend into the joint cavity or mold until covered. The gel cures quickly, forming a resilient, clear, flexible layer that insulates and protects the connection against external factors.

Q: Is the cured gel safe and environmentally friendly?

A: Yes, once cured, the gel is non-toxic, non-flammable, RoHS compliant, and stable under UV exposure. It contains no hazardous substances, making it safe for use in residential, commercial, and industrial applications.

Q: Can this gel be used with all types of cable connectors?

A: The formulation is designed for compatibility with most cable connectors, ensuring versatile application across a variety of connection types in the field.
