Two component gel

Name: Two component gel
Brand: Emson Power Engineers
Price: 8570.0 INR
Availability: InStock

Price 8570.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Two component gel Specification

Shape
Liquid (Self-leveling after application)

Operating Temperature
-40C to +120C

IP Rating
IP68

Power Factor
Low Dielectric Loss

Insulation Material
Silicone Gel

Mounting Type
Pour-in, In-Situ Mixing

Efficiency
99.9% Insulation Efficiency

Surface Finish
Gel-Like

Humidity %
0 - 100% RH

Overheating Protection
Thermal Stability

Feature
Non-toxic, UV Resistant, Easy Mixing Ratio

Connector Type
All Standard Cable Types

Product Type
Two Component Gel

Application
Electrical Insulation, Cable Joint Protection

Protection Level
High Dielectric Strength

Frequency (MHz)
50 - 60 Hz

Rated Voltage
Up to 1 kV

Output Type
Insulating Gel

Color
Transparent

Dimension (L*W*H)
Customizable as per Cable Box

Weight
2 Kilograms (kg)

Input Voltage
Up to 1000 V

Size
Standard Kit

Phase
PHASE 3

Connection Type
Encapsulating

Material
Silicone Gel

Dielectric Strength
> 23 kV/mm

Mix Ratio (A:B)
1:1 by volume

Handling Safety
Easy Handling, No Special Precautions Required

Volume Per Set
1 Liter (Total, After Mixing)

Storage Condition
Cool, Dry Place

Packaging Type
Two Separate Bottles/Cartridges

Shelf Life
24 Months (Sealed)

Toxicity
Non-Toxic, Eco-Friendly

Curing Time
10-15 minutes at room temperature

Chemical Resistance
Excellent against Water, Salts, Oils

Two component gel Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Two component gel

Set sealing compound, 500 ml
for WP 040x x
sealing compound for refilling after changes or repairs
durability of sealing compound to processing 12 months at a storage temperature of 5 - 50 C

Effortless Mixing and Fast Curing

With a straightforward 1:1 mixing ratio by volume, this gel is easy to prepare on-site. Simply combine equal parts from both bottles or cartridges, pour into the cable joint or electrical enclosure, and allow it to self-level. The fast curing time of just 10-15 minutes at room temperature enables quick restoration of service, minimizing downtime.

Superior Electrical Insulation and Protection

Designed to meet high-performance requirements, the silicone gel offers exceptional dielectric strength exceeding 23 kV/mm, with a low dielectric loss and efficient insulation of up to 99.9%. It is engineered for use in power frequencies between 50 and 60 Hz and rated for voltages up to 1 kV, providing secure encapsulation even in challenging environments.

Safe, Eco-Friendly, and User-Centric

The product is non-toxic, eco-friendly, and does not require any special handling precautions. UV-resistant and maintaining chemical resistance to water, oils, and salts, it guarantees long-lasting protection. Its shelf life is a robust 24 months when sealed, ensuring reliability for distributors, installers, or maintenance teams.

FAQ's of Two component gel:

Q: How do I mix and apply the two-component gel for electrical insulation?

A: To use, mix equal parts of component A and B (1:1 by volume) in a clean container. Stir thoroughly until a homogeneous mixture is achieved. Pour the gel directly into the cable joint or enclosure to let it self-level and encapsulate the area. The gel will cure and set in 10-15 minutes at room temperature.

Q: What are the main benefits of using this silicone gel for cable joint protection?

A: This gel provides high dielectric strength (>23 kV/mm), superior chemical resistance to water, salts, and oils, excellent UV protection, and ease of use with an uncomplicated 1:1 mix ratio. Its non-toxic and environmentally friendly properties, together with fast curing, make it an ideal solution for safe, durable electrical insulation.

Q: When should I use this gel for insulation applications?

A: The gel is best used during installation or repair of electrical cable joints, splices, or connectors, especially where high moisture protection (IP68) and electrical insulation are required. It is effective across a wide temperature range (-40C to +120C) and can be applied in humid or wet environments.

Q: Where can I store unused gel components, and what is their shelf life?

A: Store the unopened gel components in a cool, dry place away from direct sunlight. When kept sealed, the product retains its effectiveness for up to 24 months. Always ensure containers are tightly closed after each use to maintain quality.

Q: What cable types and box dimensions is this gel compatible with?

A: The gel accommodates all standard cable types and is suitable for both standard and custom-sized cable boxes or enclosures. Its liquid, self-leveling nature allows it to adapt easily to various shapes and sizes, providing complete encapsulation and protection.

Q: Is any personal protective equipment (PPE) required during handling or application?

A: No special safety precautions or PPE are required for handling this gel. It is formulated to be non-toxic and safe for use, although standard good industrial hygiene practices are recommended.

Q: What makes this product eco-friendly and efficient for industry use?

A: Formulated with non-toxic, UV-resistant, and environmentally benign ingredients, this gel minimizes environmental impact without compromising electrical performance. Its ease of preparation, reactivity under ambient conditions, and robust protection make it a sustainable and effective choice for cable insulation.
