Cable Junction Boxes IP 66/67/69 (Black)

Name: Cable Junction Boxes IP 66/67/69 (Black)
Brand: Emson Power Engineers
Price: 17540.0 INR
Availability: InStock

Price 17540.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66/67/69 (Black) Specification

Feature
UV-resistant, halogen free, weatherproof, flame retardant

Humidity %
Max 95% (non-condensing)

Connector Type
Screw terminal blocks

Operating Temperature
-40C to +85C

Mounting Type
Wall/Surface mounting

Overheating Protection
Thermally stable body

Insulation Material
ABS with high dielectric strength

IP Rating
IP66, IP67, IP69

Surface Finish
Matte / Smooth

Shape
Rectangular

Product Type
Cable Junction Box

Application
Electrical cable management; distribution

Protection Level
High (IP 66/67/69)

Frequency (MHz)
50/60 Hz

Rated Voltage
Up to 690V AC/DC

Energy Consumption
Passive device, not applicable

Output Type
Terminal connection output

Color
Black

Dimension (L*W*H)
110 x 110 x 66 mm

Weight
5 Kilograms (kg)

Input Voltage
Up to 690V

Size
255X355X122

Phase
PHASE 3

Connection Type
Screw terminal

No Of Poles
2 to 8 poles

Material
High impact ABS plastic

Lid Fixation
Four-screw lid with captive screws

Cable Entry Size
M20, M25 knockouts

Ingress Protection Test
Passed water jet, temporary immersion, and high-pressure wash tests

Earth Terminal
Integrated earth continuity terminal

Standards Compliance
IEC 60529, RoHS compliant

Seal Type
Silicone or EPDM gasket

Reusable/Disposable
Reusable

Flammability Rating
UL94 V-0

Impact Resistance
IK08

UV Resistance
Yes, suitable for outdoor use

Cable Junction Boxes IP 66/67/69 (Black) Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66/67/69 (Black)

Experience unassailable safety and versatility with our Cable Junction Boxes IP 66/67/69 (Black) at an unbeatable price. Crafted from high-impact, UV-resistant ABS plastic, these boxes promise unparalleled protection for electrical cable management and distribution, supporting 2 to 8 poles and up to 690V AC/DC. The four-screw lid, silicone or EPDM gasket, and integrated earth terminal ensure resilience against water, dust, and environmental stresses. Limited stock available-advance purchase recommended. Fully compliant with IEC 60529 and RoHS standards, these classic and reusable boxes excel in both general and demanding outdoor applications.

Versatile Applications Across Industries

Cable Junction Boxes IP 66/67/69 (Black) are ideal for a wide range of installation sites, from industrial facilities to commercial complexes and outdoor locations. These boxes are engineered for reliable electrical cable management and distribution, offering superior protection in challenging environments due to their UV resistance and weatherproof construction. General uses include safe housing of cable terminations and connections where ingress, corrosion, and impact resistance are essential.

Efficient Supply and Seamless Dispatch Process

From transportation to packing and dispatch, each Cable Junction Box is carefully handled to ensure safe delivery to your doorstep. Available at leading FOB ports across India, we ensure a consistent supply ability to meet bulk or urgent requirements. Samples are available to help you assess quality before committing any significant outlay, making your procurement process straightforward and low-risk.

FAQ's of Cable Junction Boxes IP 66/67/69 (Black):

Q: How does the high IP rating benefit users of this cable junction box?

A: The IP66, IP67, and IP69 ratings ensure the junction box is protected against water ingress, dust, and high-pressure washing, making it highly reliable for outdoor, industrial, and harsh environments.

Q: What are the primary application areas for these junction boxes?

A: These junction boxes are ideal for electrical cable management and distribution across industries, including manufacturing plants, commercial spaces, outdoor installations, and utility connections requiring robust environmental protection.

Q: What process should be followed for proper installation and mounting?

A: For correct installation, secure the box onto a wall or surface using the mounting points, insert cables through M20 or M25 knockouts, and fasten cables with screw terminal blocks, ensuring earth continuity through the integrated terminal.

Q: When should I consider advance purchase of this product?

A: Advance purchase is advised due to limited stock and high demand, ensuring timely project execution especially for large-scale or time-sensitive installations.

Q: Where can these cable junction boxes be supplied from?

A: They are available through distributors, manufacturers, suppliers, and traders across India, with dispatch from key FOB ports for nationwide and international delivery.

Q: What makes this cable junction box a classic choice for electrical professionals?

A: Its classic design, compliance with international standards, flame retardancy, unassailable protection, and reusable, halogen-free construction make it a trusted solution for professional cable management.
