Cable Junction Boxes IP 66 (Grey) with integrated membranes

Name: Cable Junction Boxes IP 66 (Grey) with integrated membranes
Brand: Emson Power Engineers
Price: 610.0 INR
Availability: InStock

Price 610.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66 (Grey) with integrated membranes Specification

Insulation Material
Thermoplastic (PC/ABS)

Connector Type
Membrane Gland, Screw Terminal

Surface Finish
Matte / Textured

Shape
Rectangular

IP Rating
IP66

Overheating Protection
Yes (Thermally Resistant Housing)

Humidity %
Up to 95% RH

Power Factor
N/A (Passive Device)

Feature
Weatherproof, UV resistant, Flame Retardant, Integrated Membranes

Operating Temperature
-25C to +60C

Mounting Type
Surface Mount, Wall Mounted

Efficiency
N/A (Passive Device)

Product Type
Cable Junction Box

Application
Electrical Cable Management, Wire Enclosure, Outdoor/Indoor Installations

Protection Level
IP66

Frequency (MHz)
50/60 Hz

Rated Voltage
Up to 400 V AC

Energy Consumption
N/A (Passive Device)

Output Type
Cable Output

Color
Grey

Dimension (L*W*H)
85 mm x 85 mm x 40 mm

Weight
5 Kilograms (kg)

Input Voltage
Up to 400 V AC

Size
85 x 85 x 40 mm

Phase
Single Phase

No Of Poles
1

Material
Polycarbonate (PC) / ABS Plastic

Connection Type
Screw Terminal, Membrane Entry

Accessories Available
Mounting screws, cable ties, wall plugs

Sealing Type
Silicone Gasket (pre-installed)

Service Temperature
-25C to +60C

UV Resistance
Yes, for outdoor use

Standards Complied
IEC 60529, EN 60670-22

Corrosion Resistance
High, suitable for harsh environments

Pack Includes
Box body, sealing lid, screws, integrated grommets

Flammability Rating
UL94 V-2 or better

Suitable Cable Diameter
4 mm - 14 mm

Lid Fixing
4 Captive Screws, Quick Release

Number of Membranes
4 Sides + Base

RoHS Compliance
Yes

Recyclability
100% Recyclable Body

Cable Entry Type
Integrated Membrane, Knockouts

Cable Junction Boxes IP 66 (Grey) with integrated membranes Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66 (Grey) with integrated membranes

Material	PP (polypropylene)
Brand	Hensel
rated insulation voltage	Ui = 690 V a.c./d.c.
rated current	20 A
degree of protection	IP 66
width	93 mm
height	93 mm
depth	62 mm
weight	0,129 kg
tightening torque for terminal	0.5 Nm
in accordance with	IEC 60670-22

Reliable Outdoor Cable Protection

Designed to withstand extreme weather and harsh environments, our junction boxes are IP66 rated, sealed with a silicone gasket, and UV resistant. The robust polycarbonate/ABS body ensures high impact resistance and corrosion protection, making them ideal for outdoor and industrial installations.

Flexible Installation Options

Easily install our boxes on walls or surfaces using included accessories, such as mounting screws, cable ties, and wall plugs. The four side and base integrated membranes accommodate various cable sizes, simplifying customized wiring layouts in both new and retrofit projects.

FAQ's of Cable Junction Boxes IP 66 (Grey) with integrated membranes:

Q: How do I install cables into the IP66 junction box with integrated membranes?

A: To install cables, simply push the cable (4-14 mm diameter) through the integrated membrane on any of the four sides or base. The pre-installed silicone gasket and the membrane design maintain the IP66 weatherproof seal, ensuring no water or dust ingress.

Q: What environments are these IP66 cable junction boxes suitable for?

A: These boxes are ideal for outdoor or indoor use, especially in harsh or corrosive environments. Their UV and flame resistance, along with high ingress protection, make them suitable for exposed locations in industrial, residential, and commercial settings.

Q: When should I choose a box with a UL94 V-2 flammability rating or better?

A: Choose UL94 V-2 or better rated boxes when fire safety is important, such as in industrial plants, outdoor installations, or areas where compliance with fire protection standards is required.

Q: Where can these junction boxes be mounted?

A: They are designed for wall or surface mounting using the supplied accessories. Suitable locations include exterior building walls, basements, rooftops, warehouses, or any area requiring protected cable connections.

Q: What benefits do integrated membranes offer over traditional cable entries?

A: Integrated membranes permit quick and tool-free cable entry while maintaining a weatherproof seal. This reduces installation time and ensures ongoing protection without the need for extra glands or fittings.

Q: How do I maintain the IP66 sealing after installation?

A: Ensure the lid is securely fastened with the four captive screws and that the silicone gasket is intact. Avoid damaging the membrane beyond the cable diameter and do not remove the pre-installed gasket, as it is key to preserving the IP66 seal.

Q: What is included in the packaging and are there accessories available?

A: Each pack includes the box body, sealing lid, captive screws, and integrated grommets. Accessories like mounting screws, cable ties, and wall plugs are also available for ease of installation.
