KV PC Small - type Distribution Boards IP 65

Name: KV PC Small - type Distribution Boards IP 65
Brand: Emson Power Engineers
Price: 4620.0 INR
Availability: InStock

Price 4620.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

KV PC Small - type Distribution Boards IP 65 Specification

Humidity %
Up to 95% (Non-condensing)

Shape
Rectangular

Overheating Protection
YES

Efficiency
>98%

Connector Type
Copper Busbar

Insulation Material
Polycarbonate

Feature
UV Resistant, Safe Operation, High Strength

Power Factor
1.0

IP Rating
IP65

Mounting Type
Wall Mounted / Surface Mounted

Surface Finish
Smooth PC Surface

Operating Temperature
-25C to +80C

Product Type
Distribution Board

Application
Electrical Circuit Distribution & Protection

Protection Level
Class II

Frequency (MHz)
50 Hz

Rated Voltage
230V/400V AC

Energy Consumption
Negligible

Output Type
Terminal Block

Color
Light Grey

Dimension (L*W*H)
230 x 180 x 100 mm

Weight
5 Kilograms (kg)

Input Voltage
230V AC

Phase
PHASE 3

Size
200X238X111

No Of Poles
Single / Double / Triple

Material
Polycarbonate (PC)

Connection Type
Screw Terminal

Number of Ways
4, 6, 8, 12 ways available

Cable Entry
Knockout on all sides

Flame Retardance
V2 grade

Locking System
Snap fit/Optional key lock

Mechanical Impact Resistance
IK08

Window Cover
Transparent polycarbonate

Ingress Protection
Dust proof and splash proof

KV PC Small - type Distribution Boards IP 65 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About KV PC Small - type Distribution Boards IP 65

9 modules: 1 x 9 x 18 mm
without PE and N terminal
1-row
box walls without knockouts
order PE/N terminals separately
for indoor (normal environment and/or protected outdoor) and outdoor installation (harsh environment and/or outdoor)
for the installation of DIN rail equipment up to 63 A, top hat profile 35 mm
with transparent lid, sealable
locking device for hinged lid and sealing facility see accessories
with cable entry cover
protective cover can be cut out
degree of protection: IP 65
colour: grey, RAL 7035

Enhanced Safety & Protection

With IP65 rating for dust and splash proofing, and flame retardant V2-grade polycarbonate construction, KV PC Small distribution boards ensure electrical safety in demanding environments. Overheating protection, UV resistance, and Class II protection level further enhance reliability and operator safety.

Flexible Configurations & Easy Installation

These distribution boards come in multiple way options (4, 6, 8, 12) and support single, double, or triple poles, making them adaptable for residential, commercial, or industrial use. Knockouts on all sides and screw terminals enable straightforward cable entry and secure connections.

Durability & Smart Design

Built with high-strength polycarbonate and featuring a smooth finish, these boards withstand mechanical impacts (IK08) and extreme temperatures. Snap-fit or optional key locking systems provide extra security, while the transparent cover enables easy inspection. The light grey, rectangular design blends seamlessly in various installations.

FAQ's of KV PC Small - type Distribution Boards IP 65:

Q: How do I install the KV PC Small-type Distribution Board?

A: The distribution board can be mounted on a wall or any suitable surface. Use pre-designed knockouts on all sides for cable entry, and secure connections via the screw terminal blocks. Ensure the board is installed within its specified operating temperature range for optimal safety.

Q: What are the benefits of the transparent polycarbonate window cover?

A: The transparent cover, made from V2-grade flame-retardant polycarbonate, allows for quick visual inspection without opening the board. This material offers high impact resistance and UV stability, ensuring long life and enhanced safety.

Q: When should I choose between snap fit and key lock options?

A: Snap fit is ideal for easy access in low-risk environments, while the optional key lock is recommended for enhanced security in public or sensitive installations. Choose based on your specific operational and access control requirements.

Q: Where can these boards be used?

A: KV PC Small-type Distribution Boards are suitable for both indoor and outdoor settings, including residential, commercial, and light industrial environments across India. The IP65 rating ensures protection against dust and water ingress.

Q: What is the process for connecting electrical circuits within the distribution board?

A: Use the provided screw terminals and copper busbars for circuit connections. Ensure correct rating for phase (up to three-phase) and use proper cable entry points on the board. Always follow local electrical codes and safety standards.

Q: How does the box ensure safe operation under varying environmental conditions?

A: Thanks to its polycarbonate insulation, Class II protection, IP65 ingress protection, and ability to function in high humidity (up to 95%) and extreme temperatures (-25C to +80C), the board maintains safe electrical operation under diverse conditions.
