Cable Junction Boxes IP 66/67/69 (Grey)

Price 4340.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66/67/69 (Grey) Specification

Humidity %
Up to 95% (Non-condensing)

Overheating Protection
Provided by enclosure material

IP Rating
IP66 / IP67 / IP69

Operating Temperature
-25C to +80C

Shape
Rectangular / Square

Connector Type
Cable Gland Entry

Surface Finish
Matte / Textured

Feature
Weatherproof, Dustproof, UV Resistant, Corrosion Resistant

Mounting Type
Surface / Wall Mounted

Insulation Material
Polycarbonate / ABS

Product Type
Cable Junction Box

Application
Electrical Cable Termination & Distribution

Protection Level
IP66 / IP67 / IP69

Frequency (MHz)
50/60 Hz

Rated Voltage
Up to 690 V AC

Energy Consumption
Nil (Passive Component)

Output Type
Terminal Connection

Color
Grey

Dimension (L*W*H)
Varies - e.g., 100x100x70 mm, 150x110x70 mm, 200x150x80 mm

Weight
5 Kilograms (kg)

Input Voltage
Up to 690 V

Phase
PHASE 3

Size
225X295X122

No Of Poles
Up to 4 Poles

Connection Type
Screw / Clamp

Material
Polycarbonate / ABS (Flame Retardant Plastic)

Lid Type
Screw Fixed / Snap-On

UV Stability
Yes, suitable for outdoor use

Ingress Protection Tests Passed
IEC 60529 Certified

Impact Resistance
IK08 / IK09

Sealing Gasket
Silicone / Rubber

Halogen Free
Yes

Cable Entry
Pre-punched / Knockout

Fire Class
UL94-V2 or V0

Standards Compliance
IEC 60670, RoHS Compliant

Cable Junction Boxes IP 66/67/69 (Grey) Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66/67/69 (Grey)

Commanding attention in the electrical components domain, our Cable Junction Boxes IP 66/67/69 (Grey) serve as cost-effective solutions for uncompromising cable management. These top-rated enclosures, available with fire class UL94-V2 or V0 and constructed from flame-retardant polycarbonate/ABS, guarantee unassailable protection against water, dust, UV, and mechanical impact (IK08/IK09). Utilise our offer for boxes supporting up to 690 V AC, suitable for outdoor environments. With halogen-free, RoHS-compliant design and versatile options-snap-on or screw lids, pre-punched/knockout entries-these virtuoso junction boxes set the industry standard for safety, reliability, and value.

Where to Install & Key Advantages of Cable Junction Boxes

Cable Junction Boxes IP 66/67/69 (Grey) are ideal for outdoor and indoor installations such as industrial plants, commercial facilities, renewable energy hubs, and public infrastructure requiring robust cable termination and distribution. Simply surface or wall mount in environments subject to dust, moisture, sunlight, or harsh weather. These boxes boast special features like weatherproofing, UV resistance, high impact strength, and halogen-free construction, ensuring a secure and long-lasting enclosure for critical electrical connections.

Sample Policy, Supply Ability & Packaging Details

Sampling is designed to accommodate various project outlays and allows clients to evaluate product quality before committing to greater purchase volumes. Our competitive list prices and adaptable rate structures ensure robust supply capabilities across India. Each Cable Junction Box is meticulously packaged with protective materials for safety during transit, whether ordered individually or in bulk. All consignments include product documentation and standard accessories, delivering reliability with every shipment.

FAQ's of Cable Junction Boxes IP 66/67/69 (Grey):

Q: How do I choose between the screw fixed and snap-on lid types for these junction boxes?

A: Screw-fixed lids offer enhanced sealing and tamper resistance, ideal for critical or high-vibration settings, while snap-on lids provide quicker access for routine inspections or maintenance. Select based on your frequency of access and security needs.

Q: What types of environments are these cable junction boxes suitable for?

A: These boxes are engineered to withstand harsh outdoor and indoor conditions, such as extreme temperatures, high humidity (up to 95%), UV exposure, dust, and water ingress, meeting IP66, IP67, and IP69 standards for unyielding protection.

Q: When should I use pre-punched versus knockout cable entry points?

A: Pre-punched entries facilitate straightforward, tool-free installation for standard cable sizes, making them ideal for fast setups. Knockout entries, on the other hand, provide greater flexibility for custom configurations and various cable diameters.

Q: Where can I purchase these cable junction boxes in India?

A: They are available through leading distributors, manufacturers, service providers, suppliers, and traders across India. Contact your preferred supplier or visit authorized dealers for genuine products and support.

Q: What is the process for electrical cable termination using these enclosure boxes?

A: To terminate cables, mount the box securely, select the entry points, fit cable glands, and connect wires to the provided terminals using screw or clamp connections. Ensure the sealing gasket is properly aligned before closing the lid.

Q: What are the benefits of using UL94-V2 or V0 flame-rated junction boxes?

A: These flame ratings offer significant fire resistance, reducing the risk of electrical fire propagation and ensuring enhanced safety for both personnel and equipment, in compliance with strict industry standards.
