Cable Junction Boxes IP 66/67 with PE Inlay

Name: Cable Junction Boxes IP 66/67 with PE Inlay
Brand: Emson Power Engineers
Price: 885.0 INR
Availability: InStock

Price 885.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66/67 with PE Inlay Specification

Shape
Rectangular

Overheating Protection
Yes (high-insulation enclosure)

Humidity %
up to 95% non-condensing

Insulation Material
PE Inlay

IP Rating
IP66/IP67

Operating Temperature
-30C to +80C

Feature
Waterproof, dustproof, high-impact resistance, UV resistant

Mounting Type
Wall / Surface / DIN rail mount

Connector Type
Cable gland compatible

Surface Finish
Matte

Product Type
Cable Junction Box

Application
Electrical wiring, cable management, outdoor/indoor installations

Protection Level
IP66/67

Frequency (MHz)
50/60 Hz

Rated Voltage
up to 500V AC

Energy Consumption
N/A (Passive Device)

Output Type
Terminal Block / Cable Entry

Color
Grey lid, black base

Dimension (L*W*H)
110 x 80 x 55 mm

Weight
5 Kilograms (kg)

Size
93X93X62

Input Voltage
up to 500V

Phase
PHASE-3

Material
Polycarbonate with PE (Polyethylene) Inlay

Connection Type
Screw terminal

No Of Poles
Single / Multiple Options

Flame Class
UL94-V2

Lid Fastening
4-point screw fixing

Cover Type
Screw-fitted transparent or opaque lid

Torque Requirement
0.8 Nm max

Compliance
CE Certified, RoHS Compliant

Environment Suitability
Suitable for outdoor and harsh environments

UV Resistance
Yes

Impact Resistance
IK08

Cable Gland Size Compatibility
M16/M20

Box Lifespan
10+ years (indoor/outdoor usage)

Knockouts
Multiple cable entry knockouts on sides

Ingress Protection Test
Passed water and dust tightness test (EN 60529)

Cable Junction Boxes IP 66/67 with PE Inlay Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66/67 with PE Inlay

Discover the Cable Junction Boxes IP 66/67 with PE Inlay-a praiseworthy solution famed for its robust design and eminent reliability. Crafted from high-impact polycarbonate with UV and flame resistance (UL94-V2), this box ensures unbeatable safety and longevity in any setting. Its cost-effective build boasts a transparent or opaque screw-fitted lid, multiple knockouts, and a torque-friendly assembly. Fully CE and RoHS compliant, it offers both dust and water tightness (EN 60529) for seamless indoor and outdoor cable management. Get it now to access elegant, trustworthy protection for your electrical connections!

Versatile Applications for Demanding Environments

Cable Junction Boxes IP 66/67 with PE Inlay are expertly designed for electrical wiring and cable management across various environments. These boxes are ideal for surface, wall, and DIN rail installations in both indoor and outdoor locations. Their waterproof and dustproof properties make them perfect for harsh climates, construction sites, factories, and commercial setups, ensuring safe connections and reliable operation wherever robust cable protection is required.

Efficient Delivery and Reliable Export Market Solutions

Serving India's main domestic market, these esteemed Cable Junction Boxes are distributed by trusted manufacturers, suppliers, and service providers. Prompt delivery and customer satisfaction are priorities, with products readily available at the lowest price for bulk and export markets. Flexible payment terms-such as advance payment, cash on delivery, or bank transfer-suit a range of clients, and efficient shipping ensures your order is fulfilled on time across the country or for export.

FAQ's of Cable Junction Boxes IP 66/67 with PE Inlay:

Q: How do I install the Cable Junction Boxes IP 66/67 for maximum protection?

A: To achieve optimal protection, mount the box on a wall, surface, or DIN rail using the provided 4-point screw fixing system. Ensure all cable glands and knockouts are securely fitted to maintain the IP66/67 rating and use appropriate torque (0.8 Nm max) on all screws.

Q: What environments are these junction boxes suitable for?

A: These junction boxes are built for both indoor and outdoor use, especially in environments prone to water, dust, or UV exposure. They excel in industrial settings, construction sites, and any application requiring high-impact resistance and long-term weather protection.

Q: When should I choose the PE Inlay variant of the junction box?

A: Opt for the PE Inlay version when seeking additional insulation and impact protection. The PE inlay enhances heat resistance and is ideal for installations exposed to fluctuating humidity and temperature.

Q: Where can I use these boxes in electrical projects?

A: Use these boxes for cable management, wire connections, and as protection nodes in electrical circuits. They are especially useful for connecting phase-3 and multi-pole lines in commercial and residential setups.

Q: What are the benefits of the transparent vs. opaque lid options?

A: The transparent lid allows easy inspection of connections without opening the box, ideal for frequent checks. The opaque (grey) lid provides added security and conceals wiring for enhanced safety and aesthetics.
