Cable Junction Boxes IP 66 (Grey) with integrated membranes

Send Inquiry

Request To Call Back

Cable Junction Boxes IP 66 (Grey) with integrated membranes

Name: Cable Junction Boxes IP 66 (Grey) with integrated membranes
Brand: Emson Power Engineers
Price: 1925.0 INR
Availability: InStock

Price 1925.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Cable Junction Boxes IP 66 (Grey) with integrated membranes Specification

Insulation Material
Polycarbonate (self-extinguishing)

IP Rating
IP66

Overheating Protection
Provided by construction and material choice

Surface Finish
Smooth, matte finish

Connector Type
Cable gland/integrated membrane entry

Mounting Type
Wall mount, Surface mount

Humidity %
Up to 95% RH (non-condensing)

Shape
Rectangular

Feature
Integrated cable entry membranes, weatherproof, UV stabilized, flame retardant

Operating Temperature
-25C to +80C

Product Type
Cable Junction Box with Integrated Membranes

Application
Electrical wiring, cable management, industrial & outdoor installations

Protection Level
IP66

Frequency (MHz)
50/60 Hz

Rated Voltage
Up to 400 V AC

Output Type
Terminal block (user configurable)

Color
Grey

Dimension (L*W*H)
110 x 110 x 66 mm

Weight
5 Kilograms (kg)

Size
Standard (110 x 110 x 66 mm)

Phase
Single

Input Voltage
Up to 400 V

Connection Type
Screw terminal/connectors

Material
High Impact Polycarbonate (PC)

No Of Poles
1

Lid Fastening
4 captive stainless steel screws

Sealing Gasket
PU formed-in-place gasket

Flammability Rating
UL94 V-0

Service Life
>10 years (weather protected installation)

Degree of Protection
Dust tight and protected against powerful water jets

Impact Resistance
IK08

Internal Mounting Options
PCB tray/terminal rail slots

Cable Entry Membranes
6 integrated membranes (3 each side)

UV Resistance
Yes

Halogen Free
Yes

Cable Junction Boxes IP 66 (Grey) with integrated membranes Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Days

About Cable Junction Boxes IP 66 (Grey) with integrated membranes

Material	Polycarbonate
Shape	Square
Size	130X180X77
Ingress Protection	IP66
Mounting Type	Wall Mount
Cover Type	Screwed
With Terminal Block	No
Color	White
Availability	In Stock

Robust Protection Meets Versatile Application

With an IP66 rating, this junction box protects electrical connections from dust and powerful water jets. Its construction from high-impact polycarbonate and a formed-in-place PU gasket ensures reliable performance in extreme temperatures, high humidity, and outdoor conditions. The box is flame-retardant, UV-stabilized, and impact-resistant, making it ideal for demanding environments.

Seamless Installation and Cable Management

The integrated cable entry membranes allow for rapid, tidy installation without specialized tools. Internal mounting slots accommodate PCB trays or terminal rails, while the captive stainless steel screws ensure secure lid fastening. Wall and surface mounting options increase flexibility for electricians and industrial installers.

FAQ's of Cable Junction Boxes IP 66 (Grey) with integrated membranes:

Q: How does the IP66 rating benefit the installation of this cable junction box?

A: An IP66 rating means the box is completely dust-tight and protected against powerful water jets, making it ideal for use in outdoor and industrial environments where exposure to harsh weather or cleaning is common.

Q: What types of cable connections can be used with this junction box?

A: This junction box supports screw terminals and connectors with cable entry via integrated membranes or cable glands, offering flexibility for different wiring configurations.

Q: Where is this product most suitable for use?

A: The junction box is designed for applications in electrical wiring, cable management, and is especially well-suited to industrial and outdoor installations due to its weatherproof, UV-resistant, and flame-retardant characteristics.

Q: When should I consider replacing or inspecting the junction box?

A: With a service life of over 10 years in weather-protected installations and constructed from durable polycarbonate, routine inspections should be done annually, or if external damage is visible.

Q: What makes this cable junction box safe during operation?

A: The box uses high-impact, self-extinguishing polycarbonate with a UL94 V-0 flammability rating, features a PU sealing gasket for ingress protection, and is halogen-free to minimize hazardous emissions during fire incidents.

Q: How do I mount and install the junction box?

A: Installation is straightforward: mount the box on a wall or surface using the built-in mounting points, use the integrated membrane entries for cable management, and secure the lid with four captive stainless steel screws for optimal protection.

Q: What are the benefits of using integrated cable entry membranes?

A: Integrated membranes offer tool-free and flexible cable entries, ensuring a secure seal around cables while maintaining the box's protection standards and simplifying future modifications or additions.
